| محل منبع: | چین |
|---|---|
| نام تجاری: | fanryn |
| گواهی: | BS476, EN13501 12018, CE |
| شماره مدل: | پانل سقفی فایبرگلاس |
| مقدار حداقل تعداد سفارش: | 1*40HQ |
| قیمت: | 0.5-3$ per square meter |
| جزئیات بسته بندی: | کارتن یا کیسه پلاستیکی |
| زمان تحویل: | 10-15 روز |
| شرایط پرداخت: | T/T |
| قابلیت ارائه: | ما می توانیم 1 * 40HQ را ظرف 10-15 روز تولید کنیم |
| ضریب جذب صدا: | 0.8-0.9 | تراکم: | 70-130 کیلوگرم بر متر مکعب |
|---|---|---|---|
| مواد: | پشم شیشه | تاثیر زیست محیطی: | قابل بازیافت و سازگار با محیط زیست |
| ضخامت: | 15ميلي متر، 20ميلي متر، 25ميلي متر | برنامه: | عایق حرارتی ساختمان، تجهیزات صنعتی |
| روش نصب: | ◆از شبکه های در معرض دید استفاده کنید، عرض شبکه ها: 15 میلی متر یا 24 میلی متر ◆ کاشی ها به راحتی بر | مقاومت در برابر آتش: | غیر قابل احتراق، کلاس A |
| هدایت حرارتی: | >=0.4 (m2.k/w) | جذب آب: | <1% |
| برجسته کردن: | fireproof fiberglass ceiling tile,eco-friendly acoustic insulation panels,square fiberglass ceiling tiles |
||
Products Description
FANRYN fiberglass ceiling board is manufactured from high density fiberglass wool. The visible face has a decorative fiberglass tissue and the back of the tile is covered with normal tissue. The four edges are sealed and square. The tiles will be parallel to grids system after installation.
![]()
![]()
![]()
Product feature of the fiberglass ceiling panel
-Non-Combustible Safety: Certified as an inherently fire-resistant material, it provides reliable protection and ensures full compliance with the most stringent building safety standards and fire codes.
-Exceptional Dimensional Stability: Engineered to resist sagging, warping, or delamination over time, it maintains long-term structural integrity and a consistently flat, seamless installed appearance for the life of the installation.
-Superior Acoustic Performance: Delivers excellent sound absorption, significantly enhancing acoustic comfort and effective noise control in a wide range of interior environments, from offices to residential spaces.
-Eco-Conscious Building Material: Classified as a premier green building product, it supports sustainable construction practices and contributes directly to environmental certification goals such as LEED and BREEAM.
-Versatile Aesthetic Finishes: Available laminated with decorative fiberglass tissue or PVC facing, offering both durability and design flexibility to meet diverse architectural and interior design requirements.
Product Specifications
|
Material |
|
|
Density |
90-130kg/m3 |
|
Face |
Painting laminated with decorative fiberglass tissue or PVC facing |
|
Color |
White, black and others to order |
|
Fire-resistant |
Class A |
|
Thermal-resistant |
≥0.5 (m2·k/w) |
|
NRC |
0.9-1.0 |
|
Humidity |
Dimensionally stable with RH up to 95% at 40℃,no sagging, wrapping or delaminating |
|
Moisture rate |
≤1%(JC/T670-2005) |
|
Environmental impact |
Tiles and packing are fully recyclable |
|
safety |
Limit of radionuclides in building materials specific activity of 226Ra: Ira≤1.0 specific activity of 226Ra, 232Th, 40K: Ir≤1.3 |
Packing and Loading Quantity for Containers
|
SIZE |
CARTON/40HQ |
PIECES/CARTON |
M2/40HQ |
|
600*600*15MM |
532 |
20 |
3830.4 |
|
600*1200*15MM |
266 |
20 |
3830.4 |
|
600*600*20MM |
532 |
15 |
2872.8 |
|
600*1200*20MM |
266 |
15 |
2872.8 |
|
600*600*25MM |
532 |
12 |
2298.24 |
|
600*1200*25MM |
266 |
12 |
2298.24 |
Installation
![]()
-use exposed grids, grids width:15mm or 24mm
-tiles are easy to trim and install
-both inches and centimeters grids are available
Product application
classrooms, offices, shopping center, etc.
![]()
Main Facing:
![]()
![]()
![]()
![]()
Production packing of the glass wool board
Carton or plastic bag
Note: OEM is acceptable
![]()
